Posibilities
» Security hardware
» Concealed hinges
» Concealed handle
» Concealed drainage
Technické údaje
» Glazing
Max. 40 mm
Min. 26 mm
» Opening possibilities
Inward opening
Side hung
Tilt & turn
Tilt only
» Sightlines
Marco 70 – 232 mm
Hoja 70 mm
» Profile thickness
Window 1.9 mm
» Polyamide strip length
35 mm
» Maximum sash dimensions
Standard solution
Width (L) 1300 mm
Height (H) 2400 mm
HD Hardware (Side Hung)
Width (L) 1200 mm
Height (H) 3500 mm
» Maximum Sash Weight
160 Kg
Consult maximum weight and dimensions according to typologies
» Finished
Possibility of bicolor systems
Color powder coating (RAL, mottled and rough)
Wood effect powder coating
Anti-bacterial powder coating
Anodized
» Transmittance
Uw ≥ 1.0 (W/m2K)
Please consult typology, dimensions and glazing
» Acoustic insulation
Rw hasta 46 dB
» Air permeability
(EN 12207) Class 4
» Water tightness
(EN 12208) Class E1650
» Wind resistance
(EN 12210) Class C5
» CSTB Laboratory DTA Certification
Avis technique – Ref. 6/17-2363
Reference test 1.23 x 1.48 m / 1 sash
